Jednoosé geomreže

Home > Produkty > Jednoosé geomreže

Jednoosé geomreže


Jednoosé geomreže sú zvyčajne používané na účely vystuženia, vzhľadom na ich výnimočnú štruktúru, ktorá je schopná poskytnúť potrebnú pevnosť pre vystuženie zásypového materiálu a obmedziť pohyb častíc pôdy, ktoré sa zaklinia priamo do geomreže. Geomreže typu jednoosé sú charakteristické vysokou ťahovou pevnosťou v jednom smere, zvyčajne v pozdĺžnom smere (MD) a parametre v priečnom smere (CMD) sú minimalizované, podľa možností technológie výroby geomreže.


ParaGrid™

High tenacity core with a thick PE coating with strength from 30 to 200 kN/m to be used in standard soil reinforcement applications (mostly retaining structures) in any soil including aggressive ones characterized by high values of ph




ParaGrid™ HF

Similar to ParaGrid as structure but mostly used in combination with Terramesh units as primary reinforcement. Their strength varies from 90 to 250 kN/m and can be used in any soil including aggressive ones characterized by high values of ph





ParaLink™

Again a strip based structure mostly used in basal reinforcement applications (but not exclusively) as piled embankment foundations, sink holes application or foundation on soft soils. Their strength varies from 300 to 1600 kN/m and can be used in any soil including aggressive ones characterized by high values of ph




ParaDrain™

Similar to ParaGrid but with a draining capacity in the MD direction obtained by shaping the strips with a channel profile closed by a geotextile filter. This unique composite is designed to be used with very thin or cohesive soils in very demanding geotechnical situations.





Paragrid™ W

An enhanced high performance knitted geogrid characterized by a very high modulus and the lowest reduction factors. Designed for standard soil reinforcement application with a specific focus on segmental wall applications. This family is suitable for use with standard soils characterized by 4</=ph</=9
