Terramesh
Modularni sistem armiranih zemljanih zidova
Porodica Maccaferri Terramesh uključuje različite opcije oblaganja za izgradnju mehanički stabilizovanih struktura zemlje (MSE) i ojačanih nagiba tla (RSS). Sastoji se od unapred montiranih jedinica žičane mreže sa dvostrukim uvijanjem (tip 8k10) spremne za sklapanje kada stignu na gradilište. Ojačanje geomreže, maska i poklopac su jedna neprekidna ploča od mreže, koja ne zahteva operacije rezanja na licu mesta.
Terramesh jedinice su proizvedene od visokokvalitetne čelične žice plus dodatno obložene polimerom (Polimac) kako bi se obezbedio 120 godina dizajna. PoliMac je revolucionarni premaz koji može da izdrži najagresivnije uslove okoline, što dovodi do odličnog poboljšanja performansi.
PoliMac obezbeđuje:
12x otpornost na habanje
2x otpornost na hemijske agresije
4x performanse po hladnom vremenu
4x otpornost na UV zrake
Terramesh jedinice se proizvode u našim fabrikama širom sveta. Sistem upravljanja i proizvodnje u mnogim našim fabrikama je sertifikovan u skladu sa ISO 9001. Postoje tri različite opcije za oblaganje: gabion (Terramesh Sistem), vegetativno (Green Terramesh) ili arhitektonsko (Mineral Terramesh).
Terramesh sistem je modularni sistem koji se koristi za formiranje gabionskog MSE zida. Prednji deo jedinice se formira povezivanjem zadnje ploče i dijafragme sa glavnom jedinicom fascije, čime se stvaraju ćelije pravougaonog oblika koje se koriste za zatvaranje kamena. Ojačanje geomreže, maska i poklopac su jedan neprekidni panel od mreže. Terramesh sistemske jedinice se isporučuju u standardnim dužinama i ne zahtevaju sečenje na licu mesta. Nakon montaže na licu mesta, fasijska jedinica se puni odgovarajućom ispunom od gabiona. Zatim se na geomreže za ojačavanje tla postavlja konstrukcijska zatrpavanje i sabija. Green Terramesh je ekološki prihvatljiv modularni sistem koji se koristi za formiranje obraslih (zelenih) padina ojačanih zemljom (RSS) i nasipa. Korišćen je globalno na nekim od najznačajnijih infrastrukturnih šema. Sastoji se od prefabrikovanih jedinica od dvostruko upredene žičane mreže (tip 8k10) obloženih dekom za kontrolu erozije i učvršćenih zavarenim mrežastim panelom. Isporučuju se dva unapred formirana čelična podupirača za povezivanje na gradilištu kako bi se jedinica održavala pod potrebnim uglom nagiba. Ugaona prednja strana i pokrivač za kontrolu erozije su dizajnirani da olakšaju uspostavljanje prirodne vegetacije jedinica; važan zahtev Green Terramesh. Pošto su sve komponente fabrički ugrađene, Green Terramesh se brže instalira od konkurentskih sistema ojačanog tla. Jedinica se jednostavno postavlja na licu mesta, pričvrsni uglovi podržavaju čelo pod određenim uglom bez potrebe za bilo kakvom spoljnom oplatom ili oplate. Na geomreže za armiranje tla postavlja se konstrukcijska zatrpavanja, a odmah iza čeone strane postavlja se odgovarajuća ispuna. Na primer, na jedinici 'Earth Tipe' za revegetaciju, gornji sloj zemlje dobrog kvaliteta bi se postavio odmah iza prednje strane da bi se podstakla brza vegetacija padine. Mineral Terramesh je jedinstven i jednostavan za ugradnju sistem za ojačavanje tla sa kosim završnim slojem stene. Idealan je za upotrebu tamo gde se preferira moderna, čista estetika. Komponente Mineral Terramesh su fabrički montirane prethodno sastavljene jedinice spremne za brzu montažu na licu mesta sa projektnim vekom od 120 godina. Instalacija je jednostavna bez potrebe za povezivanjem između geomreže i sklopljene jedinice. Mineral Terramesh jedinicama nije potreban nikakav spoljašnji okvir zbog jako pocinkovanih zavarenih mrežastih panela i podupirača koji drže čelo pod pravim uglom tokom izgradnje. Obratite se lokalnoj Maccaferri podružnici za detalje o usklađenosti i sertifikaciji u vašoj oblasti.
TerraMesh System
Gabion-facing solution for reinforced soil walls with a vertical rock face. Its pre-assembled units form gabion cells for stone confinement, allowing the use of locally available or on-site stones whenever suitable, helping reduce material transport. Designed for demanding applications and high-load conditions, it combines fast installation, durability and a natural rock-facing.
TerraMesh Green
Vegetated-facing solution for reinforced soil slopes and embankments. Designed to promote rapid vegetation growth, it combines an angled front face, erosion control blanket and suitable topsoil to create a natural green finish. Ideal for projects where structural performance and environmental integration must work together.
TerraMesh Mineral
Architectural rock-facing solution for reinforced soil structures with a sloping mineral finish. Its pre-assembled units include welded mesh panels and bracing struts that hold the face at the correct angle during construction, with no need for external framework. Ideal for projects where structural performance, reduced stone consumption and a clean-faced aesthetic are required.
Paramesh Walls
An advanced configuration combining TerraMesh units with our monoaxial geogrids that allows reinforced soil structures to reach steeper slopes, support higher loads and reduce settlements, while optimising the use of reinforcement only where needed.
PoliMac
A tested high-performance coating designed to enhance the durability of TerraMesh units in the most demanding environments. Compared with PVC coating, PoliMac delivers significantly higher performance: 10x abrasion resistance, 2x chemical resistance, 4x cold weather performance and 4x UV resistance. This protection supports a design life of up to 120 years and helps reduce long-term maintenance needs.
Design and assessment software
Maccaferri supports TerraMesh projects with a dedicated suite of software tools. MacSTARS W helps design reinforced soil walls and slopes, performing stability checks and supporting the optimisation of the structure. MacCycle Assessment enables comparative LCA studies, evaluating the environmental impact of reinforced soil structures.
Priče o Uspehu
Izgrađeno, ne samo nacrtano
Saznajte više
The Oosterweel Link project is a new 15km-long motorway connection developed by Lantis for completing the Antwerp ring road R1 (Belgium). It is a major project in Belgium and its design started in the 1990s to find a solution to the congestion problems in and around Antwerp. The total estimated cost of the project is approximately €4. 5bn. The Antwerp ring road is a key part of the Trans-European Transport (TEN-T) Core Network. Maccaferri collaborated with the design and building of the Mechanically Stabilized Earth (MSE) walls with its main product family „Terramesh“. This is a well-known system used in Europe and in the rest of the world to support or enable the construction of infrastructures in tight urban corridors, forming retaining walls, road embankments, wing walls and bridge abutments known as Geosynthetic Reinforced Soil-Integrated Bridge Systems (GRS-IBS). „Terramesh“ double twist steel wire mesh reinforcements have been used in combination with ParaLink® and Paragrid® geogrids representing an evolution and a significant advantage for both cost-effectiveness and performance. The project includes 15. 000 facing sqm of „Terramesh Green®“, 14. 000 facing sqm of „Terramesh Mineral® and System® and 5. 000 facing sqm of gabion cladding.
Saznajte više
The construction of part of the new Hector Hennaulaan bridge over the R0 motorway in the municipality of Zaventem, Belgium, required the construction of new access roads to the bridge. The designer adopted the solution, where the two access ramps had to be built using a reinforced soil structure. The choice of Mineral Terramesh was very well appreciated because of the ease of construction and because of the nice external finishing. Moreover, the Municipality did not want to carry any maintenance of green facings under the bridge abutments, therefore the stone facing has been very well appreciated by the public authority. on the contrary, the green facing of Green Terramesh was adopted for all other reinforced soil structures, creating a more pleasant and natural facing.
Saznajte više
The Oosterweel Link project is a new 15km-long motorway connection developed by Lantis for completing the Antwerp ring road R1 (Belgium). It is a major project in Belgium and its design started in the 1990s to find a solution to the congestion problems in and around Antwerp. The total estimated cost of the project is approximately €4. 5bn. The Antwerp ring road is a key part of the Trans-European Transport (TEN-T) Core Network. Maccaferri collaborated with the design and building of the Mechanically Stabilized Earth (MSE) walls with its main product family „Terramesh“. This is a well-known system used in Europe and in the rest of the world to support or enable the construction of infrastructures in tight urban corridors, forming retaining walls, road embankments, wing walls and bridge abutments known as Geosynthetic Reinforced Soil-Integrated Bridge Systems (GRS-IBS). „Terramesh“ double twist steel wire mesh reinforcements have been used in combination with ParaLink® and Paragrid® geogrids representing an evolution and a significant advantage for both cost-effectiveness and performance. The project includes 15. 000 facing sqm of „Terramesh Green®“, 14. 000 facing sqm of „Terramesh Mineral® and System® and 5. 000 facing sqm of gabion cladding.
