Reinforced Soil Walls and Slope Reinforcement
2003
Mendoza, Argentina
Dirección Provincial de Vialidad de Mendoza
UTE HOMAQ - ROVELLA - PAEDILLE
Perilago Path – Reconstruction of Route 82
Problem
u003cpu003eFor the construction of the Potrerillos dam in the province of Mendoza. The dam was built between 1999 and 2003 by a consortium consisting of Industrias Metalúrgicas Pescarmona (IMPSA) to provide flood control, hydroelectricity and irrigation water. The main problem was that in order to build the dam it was necessary to interrupt route 82. This route connected the cities of the region, like Potrerillos and Cacheuta. Once the construction of the dam was finished, work began on the reconstruction of route 82 in order to restore the connection between Potrerillos and Cacheuta. The trace of route 82 was also redesigned to generate a tourist path in the perimeter of the lake (reservoir).u003c/pu003e
Solution
u003cpu003eThe most adequate solution for the needs of the work was the reinforced soil. The structure was designed with TerraMesh™ System, the built wall has a maximum height of 15m and a 22° inclined vertical face. It was also necessary to provide protection at the foot with Reno® mattresses, in order to protect the structure from the effect of erosion from rainwater. TECHNICAL HIGHLIGHTS 3,965 m2 of TERRAMESH™ 94.5 m3 of GABION™ 2,190 m2 of RENO MATRESS 26,600 m2 of MACTEX™ Nu003c/pu003e
Used Products

Terramesh
Rodina produktov Maccaferri Terramesh® zahŕňa rôzne možnosti lícových prvkov na budovanie konštrukcií z mechanicky stabilizovanej zeminy (MSE) a vystuPohľad
Reno Matrace Plus
Pomenované po jednej z prvých sanácií, ktoré spoločnosť Maccaferri vykonala pred viac ako 100 rokmi. Reno Matrace®, a dnes sú synonymom projektov vodoPohľad
Netkané geotextílie
Netkané geotextílie sú plošné textilné prvky, ktoré pozostávajú zo syntetických vlákien náhodne zostavených vpichovaním a/alebo tepelnými procesmi; tiPohľad
